Tilton 600 Series Alloy Floor Mounted Bias Pedal Box & Balance Bar 72-603 Clearance

Pedal box & balance bar only.

Master cylinders and throttle linkage not included (available separately).

Brand new test fitted only.

Tilton’s 600-Series 3-pedal floor mount assembly features traditional fixed-mount master cylinder and balance bar technology and provide excellent performance at competitive prices.

Description
Tilton brake pedal assemblies offer the best available value for their type.The standard of engineering, materials and workmanship that goes into the production Tilton 600-Series pedal boxes is unmatched by anything in their price range and difficult to beat regardless of budget.
Incorporating technology from the bench mark setting 900-Series, the latest generation of 600-Series pedal assemblies have been engineered to provide excellent performance at competitive prices. The newly redesigned 600-Series pedal assemblies incorporate features such as ramps to prevent balance bar tipping, high-strength 7/16" balance bars, adjustable foot pads and oil-impregnated bronze bushings at pedal pivots. As with all Tilton pedal assemblies, ergonomic principles have been applied to reduce driver fatigue and provide exceptional feedback.

Features:
Forged aluminum pedals with adjustable (vertical & horizontal) foot pads and anti-slip surfaces.
Adjustable pedal ratio (5.29:1, 5.44:1, 5.61:1, 5.75:1) enable the brake pedal to be tuned to driver preference without having to change master cylinder bore size.
Large diameter 7/16”-20 balance bar provides maximum rigidity. PTFE coated aluminum clevises for increased durability and reduced friction.
Pedal pivots feature wave washers to reduce lateral pedal movement and oil impregnated bronze bushings decrease stiction.
Lightweight aluminum frame features guide “ramps” to reduce balance bar tipping, decreasing friction and improving brake repeatability.
Adjustable clutch pedal stop prevents clutch over-stroking.

Weight: 5.5 lbs (2.5 kg)
