ZF Hall Effect Wheel Speed Sensor M12x1 GS100502
The ZF Hall Effect Wheel Speed Sensor M12x1 GS100502 is a precision automotive component designed to measure the rotational speed of a vehicle's wheel. Featuring a threaded M12x1 connection, this sensor is typically constructed with durable materials such as high-grade plastics and metal to withstand harsh operating conditions. The Hall Effect technology enables it to detect changes in magnetic fields as the wheel rotates, converting these signals into electrical pulses for accurate speed measurement. Commonly used in anti-lock braking systems (ABS) and traction control systems, this sensor plays a crucial role in vehicle safety and performance monitoring. Its compact design allows for straightforward installation and reliable operation in various automotive applications.
Product Details GS1005 Hall Effect Sensors
The Cherry GS1005 -for gear tooth speed sensors are hall effect sensors
that are designed for use in applications where ferrous edge detection
or near zero speed sensing is required.
Aluminium housing
High speed capability
Immune to rotational alignment
Compatible with unregulated power supply
Operating temperature -40 → 105 °C
Output Type: NPN
Body Styly:Barrel
Mounting Style:Panel Mount
Supply Voltage: 5 → 24 V dc
Terminal Type: Wire Lead
Maximum DC Voltage:30V
Switching Current:25 mA
Length: 65mm
IP Rating:IP68
Maximum Operating Temperature:+125°C
Housing Material:Aluminium
Reverse Polarity Protection:Yes
Minimum Operating Temperature:-40°C
