Escort Mk1 Mk2 Millington Diamond to Ford Gearbox Alloy Bellhousing - Standard

Millington Diamond to Ford based Gearbox Alloy Bellhousing - Standard fitting

New design Millington Diamond specific bellhousing, for use with block mounted starter motors with the small diameter flywheels as used on millington Diamond engines; both series 1 and series 2.
Allows extra clearance over the RS2000 type bellhousing
Ideal for use with sequential gearboxes with Ford Type-9/Rocket bolt pattern
Revised Version bellhousing with the addition of 2x extra mounting points in the dry sump pan , now the bellhousing includes a shield plate and 2x extra dowels

The sump pan will require 2x 10mm x 1.5 helicoil inserts fitting for the extra 2 mounting points

Thicker casting wall section with extra webs added to top and bottom flanges for extra strength
Hellicoiled engine mounting bolt holes
Gearbox mounting bolt holes: 12mm clearance for cap head bolts

AP Racing CP6859-54 slave cylinder mounting boss - (cylinder not included)
Extra material left on the mounting boss - To be machined down to suit clutch height

Top quality part, precision made in the UK
